Rubber Vulcanizing Machine
Product Summary: Hydraulicl Mechanical doublelayers automatic mould ejecting vulcanzing press
Function/performance characteristics：
Mould ejecting device works with hydraulic and mechanical type.Customers can choose according to their needs.The new design concept,strong technical force and advanced manufacturing processes of the company ensures that each device can be manufactured to meet customer's individual requests."
The Main Technical Parameter
| Type | XLB-Q2600×2800 | XLB-DQ1500×2000 | XLB-D03000×3000 |
| Total Pressure(Tons) | 2500 | 1600 | 3000 |
| Plate Size(mm) | 2600×2800×90 | 1500×2000×90 | 3000×3000×100 |
| Daylight (mm) | 200 | 200 | 300 |
| Layers | 2 | 2 | 2 |
| Piston Stroke(mm) | 400 | 400 | 600 |
| Close Mould Speed (mm/s) | ≥16 | ≥16 | ≥16 |
| Open Mould Speed(mm/s) | ≥35 | ≥35 | ≥35 |
| Cylinder Diameter (mm) | φ700 | φ550 | Φ750 |
| Cylinder NO.(Pcs) | 4 | 4 | 4 |
| Motor Power (kw) | 11.0×3+22 | 11.0+15 | 11.0×2+22 |
All specification can be customized according to requirements.
