Rubber Vulcanizing Press
Product Summary: 2500T Vulcaizing Press(Frame Structure)
High Pressure and Tonnage:
With a pressing force of 2500 tons, the press is capable of vulcanizing large rubber products with ease.
The high tonnage ensures that the rubber products are pressed evenly and consistently, resulting in high-quality vulcanized products.
Description
| Type | XLB-Q3000×3000 |
| Total Pressure(Tons) | 2500 |
| Plate Size(mm) | 3000×3000×90 |
| Daylight(mm) | 1000 |
| Piston Stroke (mm) | 1000 |
| Close Mould Speed(mm/s) | ≥15 |
| Open Mould Speed (mm/s) | ≥20 |
| Hydraulic System Pressure (Mpa) | 16.5 |
| Cylinder Diameter(mm) | Φ700 |
| Cylinder NO. (Pcs) | 4 |
| Motor Power (kw) | 11. ×3+15 |
All specification can be customized according to requirements.
We can design and manufacture vulcanizing machines of various specifications based on the dimensions and technical parameters provided by users, offering the most suitable vulcanizing machine for you.
Application
